Precision ISO30 ER40 Tool Holder SK30 ISO30 Collet Chucks with HSD Pull Stud

Precision ISO30 ER40 Tool Holder SK30 ISO30 Collet Chucks with HSD Pull Stud

Model: ISO30-ER40-75L
Collet Series: ER40
Material: 20CrMnTi
Brand: RICOCNC
Product description: This CNC tool holder is SK30 ER40 toolholder, A=67mm. Well know as ISO30 collet chuck for many HSD equipped CNC routers. Balanced to 24,000 rpm @ G2.5, includes HSD pullstud and ER40 collet nut. All o
INQUIRY EMAIL

Precision ISO30 ER40 Tool Holder SK30 ISO30 Collet Chucks with HSD Pull Stud

This CNC tool holder is SK30 ER40 toolholder, A=67mm. Well know as ISO30 collet chuck for many HSD equipped CNC routers. Balanced to 24,000 rpm @ G2.5, includes HSD pullstud and ER40 collet nut. All of our ISO30 chucks are supplied with clamping nut and retaining stud.
The iso30 tool holders are ideal accessories for machining centres, point-to-point machines and CNC routers.

ISO30 ER40 Collet Chucks Product Specifications:

Taper	ISO30
Collet Series	ER40
Body Dia-Workpiece Side (in)	2.48
Body Dia-Workpiece Side (mm)	63
Gage Length (in)	2.63
Gage Length (mm)	67
Gage Length-Face Contact (in)	2.47
Gage Length-Face Contact (mm)	62.8
Lock Nut Diameter (in)	2.48
Lock Nut Diameter (mm)	63
Overall Length (in)	4.48
Overall Length (mm)	113.8
Material	20CrMnTi
Overall Diameter (in)	1.81
Overall Diameter (mm)	46
Unit of Tool	Metric or Inch
Type	V-Flange Collet Chuck
Style	Single Ended
Capacity Range (in)	0.086" - 1.02"
Capacity Range (mm)	2.2 - 26mm
Balanced to	25,000 RPM at G2.5

Except ISO30 CHUCKS FOR ER40 PRECISION COLLETS, we also have ISO30-ER32, ISO30-ER25 tool holder, HSK63F toolholder, ISO20 toolholders, etc

RicoCNC supplies a range of CNC tool parts, such as bearings, spindles, inverters, drivers,motors, controllers, collet nut, grippers, pull stud, tool forks, tool tightening stands, wrenches, ER11 collets, ER16 collets, ER20 collets, ER25 collets, ER32 collets, ER40 collets, SYOZ25 collets, SYOZ35 collets, collet sets, cnc cutters, foam mills, etc.

Welcome your inquiry.
